About Product

As the previous STORIA model, V3 offers the revolutionary LOK Technology that allows a complete compression separate lock-out system, now totally renewed with a new design, a more progressive opening, and a totally silent working.

Features

• In order to allow every rider to use a softer spring rate and increase bike traction and handling, EXT engineers have imported from ARMA the hydralic bottom out system named HBC (Hydraulic Bottom-out Control), capable to develop more than 50% of hydraulic force only on the last part of the stroke, allowing riders to avoid any kind of bottom-out issues.
• This technology allows the use of thinner bottom-out bumpers, increasing the amount of useful travel.
• STORIA V3 is designed to serve those customers who want maximum performance of a pedal-platform equipped shock, with a great support on the last millimeters of bike rear travel, with the great performance of a coilover shock.

Specification

• Metric and Imperial sizing – Standard or Trunnion mount
• 4 way adjustable (LSC-HSC-LSR-Lok proprietary system)
• High flow Ø29 mm main piston
• Ø24 mm valve piston
• Ø14 mm shaft
• New Lok Technology – Progressive opening – Silent working
• Engineered rebound circuit to separate bump and rebound oil flow
• Ultra low-friction coating
• Factory tuned HBC technology
• Very low reservoir pressure for maximum sensitivity (55 PSI)
• Full custom hydraulic setup available
• No cavitation
• Very low hysteresis for high dynamic response
• High turbulent flow for very low temperature depending
• Low friction Energize seal
• Thinner bottom-out bumper
• New rebound knob for easy spring swap
